CORRIDOR CEILING SYSTEM
INTRODUCTION
These systems are specifically designed for corridor ceiling applications. They are available in La-on, clip-in, and hook-on systems.And the system is supported by perimeter profiles installed on corridor walls to utilize the maximum ceiling area for service fittings. These systems are available in rectangular and square panels, and they are made of aluminum/galvanized steel. The system module width is decided on the basis of project requirements.It allows easy and quick access to the ceiling void without any access tools and provides easy integration with lights, ventilation ducts, and other components.
PRODUCT
- Panel Thickness –0.50 to 0.70mm
- Panel Length-Can be produced from 600 to 2500mm and custom made length are provided only on request.
- Panel Width- 300 to 500mm
- Panel Edge-Closed joint with square edge.
- Surface Finish-Plain or perforated
- Raw Material—Aluminum Alloy as per EN AW 3000 or 5000 Series / Zinc-Plated Galvanized Steel or Stainless Steel (Brush/Mirror) as per ASTM A653-01
MODULEX L PANEL SYSTEM FOR CORRIDORS
The lay-on modular panel system is simple, functional, and free-span in design; the panels are laid on the perimeter trims available in L and W shapes.It is an ideal system for corridors, hallways, etc., and usually used where the soffit level is low. It provides easy integration with lights, ventilation ducts, fire fighting systems, and other components; individual panels are removed without any tools.
